Description
Specifications
- Magnification: 24x
- Dampening: Magnetic
- Accuracy: 2.0 mm (Standard Deviation, 1 km double run leveling)
- Leveling Accuracy @ 50 m: 2.5 mm
- Telescope Aperture: 30 mm
- Telescope Image: Erect
- Field of View: 120
- Shortest Focus Distance: 0.6 m (1.97 ft)
- Stadia Constant: 100
- Addition Constant: 0
- Dimensions (L x W x H): 5.2 x 7.5 x 5.3 in. (103 x 190 x 135 mm)
- Instrument Weight: 3.5 lb (1.6 kg)
Product Description
The Spectra Precision AL24M Automatic Level is equipped with 24x magnification and a magnetic-dampened compensator. Its high-quality optics provide sharp, bright images, while stadia lines on the reticle allow easy distance calculations. With a short focusing distance, the AL24M performs exceptionally well in confined areas and on sloped terrain, making it ideal for construction, grading, and landscaping applications.
Rugged metal housing and water-resistant construction offer durability for long-term field use, while the built-in bubble mirror and optical sighting alignment make setup simple. The Spectra Precision AL24M-2 Automatic Level Kit includes a tripod and 15ft grade rod (inches).
In The Box
- AL24M Auto Level
- Allen wrench
- Pin tool
- Rain cover
- Plumb bob
- Hard Carry Case
- Tripod
- 15ft Grade Rod (Inches)
