Description
Specifications
- Laser Class: Class 2, <1mW, 520 nm green beam
- Accuracy: 1/8 in @ 30 ft (3 mm @ 10 m)
- Self-Leveling Range: 3 (0.5 tolerance)
- Range: 100 ft (30 m)
- Range (with receiver): 250 ft (75 m)
- Out of Level Indicator: Yes
- Locked Pendulum Indicator: Yes
- IP Rating: IP54 (dust/splash resistant)
- Power Source: Removable 11.1 V 2000 mAh Li-ion battery
- Operating Hours: Up to 8 hours
- Charge Time: <4 hrs
- Operating Temperature: 14F to 113F (-10C to +45C)
- Storage Temperature: -4F to 140F (-20C to +60C)
- Tripod Threads: 1/4-20 and 5/8-11
- Dimensions: 7.7 x 3.5 x 6.3 in (145 x 89 x 160 mm)
- Weight: 2.2 lbs. (1 kg)
- Warranty: 2 years (laser), 1 year (battery)
Product Description
The Spectra Precision LT360G is a professional 3-plane green laser that projects full 360 lines for unmatched jobsite coverage. With three ultra-bright planesone horizontal and two verticalit simplifies leveling, alignment, and layout tasks with fewer setups. Its self-leveling pendulum ensures accuracy of 1/8 in at 30 ft, while receiver mode extends its working range outdoors up to 250 ft.
Optimized for ceiling and interior work, the LT360G mounts easily on ceiling tracks and features a fine adjustment knob for precise 90 layouts. It runs up to 8 hours on a rechargeable lithium-ion battery and can operate while connected via USB-C for uninterrupted use. A hard case and pendulum lock protect the unit during transport and storage.
In the Box
- LT360G 3-Plane Laser
- Built-in Pivoting Base
- Bracket
- Target
- Case
- Li-Ion Batteries
- Charger
Brochures and Manuals
- Spectra Precision 360 Green Beam Plane Laser User Manual
