Description
Specifications
- Channels: 800+ (multi-constellation)
- Constellations: GPS, GLONASS, Galileo, BeiDou, QZSS, IRNSS, SBAS
- Position Rate: 10 Hz, optional up to 100 Hz
- Signal Reacquisition: <1 s
- Start Times: Cold start ~60 s, Hot start ~10 s
- Internal Memory: 32 GB; expandable via TF card, USB, SSD
- Static Accuracy: H: 2.5 mm + 0.1 ppm; V: 3.5 mm + 0.4 ppm RMS
- RTK Accuracy: H: 8 mm + 1 ppm; V: 15 mm + 1 ppm RMS
- SBAS Accuracy: H: 0.50 m; V: 0.85 m RMS
- Code Differential Accuracy: H: 0.25 m; V: 0.45 m RMS
- Interference Mitigation: Spectrum analysis, adaptive filtering, anti-jamming
- Interfaces: RS232/DB9, USB, Ethernet (100/1000 Mbit), 1PPS, Event, OSC
- Wireless: LTE, Bluetooth 2.1+EDR/4.1, Wi-Fi 802.11 b/g/n
- Networking: NTRIP Caster/Client, FTP/FTPS, 2026/09/ul>
