Toro OEM 119-8898 Red/Positive Battery Cable (8 Gauge Wire – 5/16 Eyelet/Bolt Whole – 1/4 Eyelet/Bolt Whole) Fits Select Late 32, 42, 50 Timecutter MX, SS, ZS Models.

Description

Please refer to the Images above; Product Specifications and the Model Fit Guide below to Ensure a proper fit.

• PRODUCT NUMBER AND VARIATIONS:119-8898, 119 8898, 1198898
• PRODUCT TYPE:TORO OEM RED/POSITIVE BATTERY CABLE
• NOTES & DETAILS: Toro OEM 119-8898 Red Positive Battery Cable is Primarily Used Between the Electrical Solenoid and the Engine’s Starter Assembly. 119 8898 Main Purpose is Service by Transferring Electrical Current from the Solenoid to the Engine’s Electric Starter under the Direction and Functions of the Ignition Switch and Electric Solenoid. 119 8898 Also Contains the Correct Size Battery Wire End Eyelets Needed for the Require Fasteners.
• SIZE:— in.
• COMMON SERIES APPLICATIONS: Select 32″ Timecutter ZS & SS Models – Select 42 & 50″ Timecutter ZS, SS & MX Models.

• ASSOCIATED PARTS CHART:

STARTER ASSEMBLY

1. 32128-33 – FLANGE NUT(Retains Battery Cable End or Eyelet to the Engine Starter Assembly)x1 Per Engine Starter Assembly

SOLENOID

1. 117-1197– SOLENOID(Retains the One End of the Battery Wire and Transfers Battery Current with the Different Functions of the Ignition Switch and Individual Safety Switch Circuits)x1 Per Unit
2. 139-2580 – FLANGE NUT(Retains Solenoid Cable End or Eyelet to the Solenoid Post) x1 Per Positive Solenoid

• MODEL FIT CHART:

TIMECUTTER

TIMECUTTER 32 SS Series Model Numbers74620

TIMECUTTER 32 ZS Series Model Numbers 74385

TIMECUTTER 42 SS Series Model Numbers74622, 74624, 74625, 74626, 74623, 74706, 74722

TIMECUTTER 42 ZS Series Model Numbers 74386, 74389, 74390, 74656

TIMECUTTER 42 MX Series Model Numbers74640

TIMECUTTER 50 ZS Series Model Numbers 74387,74660, 74395

TIMECUTTER 50 MX Series Model Numbers 74641, 74643, 74776, 74727, 74772

TIMECUTTER 50 SS Series Model Numbers74630, 74632, 74631, 74635, 74638, 74730
