Toro OEM 138-9804-03 Shaft Upper Cross Support Fits Toro Late 60 Timecutter Standard, My-Ride Models 75760, 75762, 75763.

Toro OEM 138-9804-03 Shaft Upper Cross Support Fits Toro Late 60 Timecutter Standard, My-Ride Models 75760, 75762, 75763.

Original price was: $6.59.Current price is: $1.98.

SKU: ANK-TYEK-4927 Category:

Description

Toro OEM 138 9804 03 Shaft Upper Cross Supports are Designed to Serve the Purpose of Retaining the Mower Deck Lift/Leverage Arm to the Frame as well as Allowing it to Pivot. Toro 138 9804 03 Is Designed forToro Late 60″ Timecutter Standard, My-Ride Models 75760, 75762, 75763 (Models with Replaceable Cast Aluminum Axles). Unlike Other Models – Models Using 138-9804-03 Require Four Shaft Cross Support Brackets and Two Lift Pivot Arms.Please refer to the Images above; Product Specifications, Special Notes, and the Model Fit guide below to ensure proper fit.

ASSOCIATED PARTS REFERENCES FOR PART NUMBER 138-9804-03 ONLY

CLICK ON THE ASSOCIATED PART NUMBER TO BE REDIRECTED

  1. 138-9753– SCREW –(Retains Upper Mower Cross Support Bracket to Mower Frame as well as Lower Mower Cross Support Gusset/Bracket and Lower Cross Support Bearing/Bushings to Upper Cross Support Bracket) x4 Per Bracket
  2. 138-2503-03– MOWER DECK PIVOT/LIFT LEVARAGE ARM (FRONT)–(Travels Across/Between the Two Frames of the Mower and Attaches to the Lift Linkage – Review Part Number Model Fit Chart to Ensure Correct Fit)x1 Per Unit
  3. 138-2504-03– MOWER DECK PIVOT/LIFT LEVARAGE ARM (REAR) – (Travels Across/Between the Two Frames of the Mower and Attaches to the Lift Linkage -Review Part Number Model Fit Chart to Ensure Correct Fit)x1 Per Unit
  4. 139-5872– LOWER MOWER DECK LIFT LEVARAGE ARM SUPPORT BEARING/BUSHING –(Attaches with the Lower Support Gusset/Bracket to the Upper Mower Cross Support Bracket and Allows for the Mower Lift Pivot/Leverage Arm to Rest into and Rotate in a Replaceable Bearing Flange Instead of Rotating Against Metal on Metal)x4 Per Unit
  5. 138-7204– LOWER MOWER DECK LIFT LEVARAGE ARM SUPPORT GUSSET/BRACKET –(Attaches with the Lower Support Bearing/Bushing to the Upper Mower Cross Support Bracket and Allows for the Mower Lift Pivot/Leverage Arm to Rest into and Rotate in a Replaceable Bearing Flange as well as retaining the Bearing/Bushing and Mower Deck Pivot Arm)x4 Per Unit

Specification

Product Number:

138980403

Brand:

Toro

Length:

4.500 IN (11.430 CM)

Width:

3.000 IN (7.620 CM)

Height:

0.750 IN (1.905 CM)

Weight:


0.701 LB (0.318 KG)

Model Fit:

60 TIMECUTTER (STANDARD) Series Model Numbers(* Model Numbers 75760, 75762)

60 TIMECUTTER (My-Ride) Series Model Numbers (* Model Numbers 75763)
